Product of the UK
|
Standard(s) |
BS EN 60669-1 |
|
Voltage Rating |
10 A(X), 250V~ |
|
Contact Gap |
Normal Gap |
|
Mounting Box Depth (Min) |
25mm |
|
Terminal Capacity |
4 x 1.0mm², 4 x 1.5mm², 2 x 2.5mm², 1 x 4.0mm² |
|
Earth Terminal Capacity |
4 x 1.0mm², 4 x 1.5mm², 2 x 2.5mm², 1 x 4.0mm² |
|
Fixing Centers |
60.3mm |
|
Size |
146mm x 86mm x 4.5mm (Plate thickness) |
|
Product Class 1 |
Face plate must be earthed |
|
Ambient Operating Temperature |
-5° to +40°C |
|
Recommended Location |
Internal Use Only |
|
Maximum Installation Altitude |
2000m |
|
IP Rating |
IP2XD |
|
Switched Poles |
Single |
|
Main Frequency |
50hz - 60hz |
|
Contact Gap Minimum |
3mm |
