| Standard(s) |
BS 1363-2, BS EN 62368-1, BS EN 62680-1-1 |
| Voltage Rating |
13 Amp, 250V~ |
| USB Amperage |
3.1 Amp |
| Contact Gap |
Normal Gap |
| Mounting Box Depth (Min) |
35mm |
| Terminal Capacity |
3 x 2.5mm², 3 x 4.0mm², 2 x 6.0mm² |
| Earth Terminal Capacity |
3 x 2.5mm², 3 x 4.0mm², 2 x 6.0mm² |
| Outlet Protection Shutter |
Yes |
| Fixing Centers |
120.6mm |
| Size |
86mm x 146mm x 4.5mm (Plate thickness) |
| Product Class 1 |
Face plate must be earthed |
| Ambient Operating Temperature |
-5° to +40°C |
| Recommended Location |
Internal Use Only |
| Maximum Installation Altitude |
2000m |
| IP Rating |
IP2XD |
| Switched Poles |
Double Pole |
| Main Frequency |
50hz - 60hz |
| Contact Gap Minimum |
3mm |
